Knipex Super-Knips 78 91 125 Electrical & precision engineering Print pliers non-flush type 125 mm
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 21.84
3
4% = € 0.95
€ 20.89
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 21.84 / piece)
€
Highlights & Details
Electronic Super-Knips®
- Precision pliers for fine cutting work e.g. in electronics and precision mechanics.
- Ground, very sharp cutting without bevel
- Cut-off with controlled micro edge offset for ultra-precise cutting even on thinnest wires and long life
- Precisely shaped cut tops and adjacent wires starting from Ø ,2 mm
- Joint with stainless steel rivet
Technical specifications
- Head dimensions A 13.50 mm
- B 9.00 mm
- D 7.50 mm
- Manufacturer part #
78 91 125
- Range of use
Electrical & precision engineering
- Length
125 mm
- Material
Tool steel
- Material properties
tempered
burnished
- Edge hardness
64 HRC
- Wire hardness (max.) soft wire
1.6 mm
- Wire hardness (max.) medium wire
1.2 mm
- Wire hardness (max.) hard wire
0.6 mm
- DIN standard
DIN ISO 9654
- Width
50 mm
- Weight
57 g
- Features
non-flush type
- Material (details)
Special tool steel in special quality, oil hardened
- Type
With very small facet with wire clamp
- Type
78 91 125
- Standards
DIN ISO 9654
- Product type
Print pliers
Variants(All information is without VAT, plus shipping costs)
Product type
Knipex Super-Knips 78 91 125 Electrical & precision engineering Print pliers non-flush type 125 mm
This article
Print pliers
Minimum order quantity: 1
Multiple: 1
€ 21.84*
Knipex Super-Knips 78 13 125 Electrical & precision engineering Print pliers flush-cutting 125 mm
Print pliers
Minimum order quantity: 1
Multiple: 1
€ 21.00*
Knipex Super-Knips 78 23 125 Electrical & precision engineering Print pliers flush-cutting 125 mm
Print pliers
Minimum order quantity: 1
Multiple: 1
€ 21.00*
Knipex Super-Knips 78 31 125 Electrical & precision engineering Print pliers flush-cutting 125 mm
Print pliers
Minimum order quantity: 1
Multiple: 1
€ 18.48*
Knipex Super-Knips 78 41 125 Electrical & precision engineering Print pliers flush-cutting 125 mm
Print pliers
Minimum order quantity: 1
Multiple: 1
€ 20.16*
Knipex Super-Knips 78 71 125 Electrical & precision engineering Print pliers flush-cutting 125 mm
Print pliers
Minimum order quantity: 1
Multiple: 1
€ 18.48*
Knipex Super-Knips 78 81 125 Electrical & precision engineering Print pliers non-flush type 125 mm
Print pliers
Minimum order quantity: 1
Multiple: 1
€ 18.48*
Knipex Super-Knips 78 03 125 Electrical & precision engineering Print pliers flush-cutting 125 mm
Print pliers
Minimum order quantity: 1
Multiple: 1
€ 19.32*
Knipex Super-Knips 78 61 125 Electrical & precision engineering Cutter pliers flush-cutting 125 mm
Cutter pliers
Minimum order quantity: 1
Multiple: 1
€ 19.32*
Documents & Downloads
Datasheet
Datasheet 822329 Knipex Super-Knips 78 91 125 Electrical & precision engineering Print pliers non-flush type 125 mm
User & Safety Instructions
User & Safety Instructions 822329 Knipex Super-Knips 78 91 125 Electrical & precision engineering Print pliers non-flush type 125 mm
Description
Precision-ground cutting with very small facet also for hard wire With wire clamp - no uncontrolled shingling of wire segments. Induction hardened blades. Blade hardness approx. 64 HRC Special tool steel, browned Precision pliers for fine cutting work e.g. in electronics and precision mechanics. Ground, very sharp blades without face. Precisely shaped cut tops and adjacent wires of Ø 0.2 mm. Shear cut with controlled micro cutting edges offset for ultra-precise cutting even thin latest wires and long life. Joint with stainless steel rivet. Extremely soft motion for fatigue-free working With opening spring and opening limit. Special tool steel, multi-stage oil-hardened
This text is machine translated.
This text is machine translated.
Features
- With opening spring and opening limit
- Precision-ground cutting with very small facet also for hard wire
- Induction hardened blades. Blade hardness approx. 64 HRC
- With wire clamp - no uncontrolled movement of the wire segments
- Precision pliers for ultra-fine cutting work e.g. in electronics and precision mechanics.
- Joint with stainless steel rivet
- Extremely soft motion for fatigue-free working
- Precise-shaped tips separate even the adjacent wires starting from Ø 0.2mm
- Special tool steel, browned
- This text is machine translated.
