LAPP Connector set EPIC® ULTRA Kit H-B 75009740 16 + PE Push-in connector 1 Set
EAN:
Part number:
Item no:
Product type
Connector set
Series
EPIC® ULTRA Kit H-B
Connection
Push-in connector
Number of pins
16
Total no. of pins
16 + PE
Datasheet (PDF)
Highlights & Details
EPIC® ULTRA KIT H-B 16 SP TS QB 11-21
Our service for you
Technical specifications
- EPIC® PIN INSERT H-BE 16
- EPIC® ULTRA H-B 16 EMC SLEEVE CASING
- Integrated SKINTOP® cable gland
- Product type
Connector set
- Series
EPIC® ULTRA Kit H-B
- Number of pins
16
- Total no. of pins
16 + PE
- Connection
Push-in connector
- Test current
IEC 16A
UL 13A
CSA 13A A
- Rated voltage
IEC: 500 V
UL: 600 V
CSA 600 V
- Case material
Metal
- Content
1 Set
- Factory colour
Grey
- Terminal Ø (max.)
21 mm
- Clamp Ø
11 mm
- Core cross section (max.)
2.50 mm²
- Core cross section (min.)
0.14 mm²
- Features
Chemical-resistant
EMC type
Transverse brace pin
1x cable exit (lateral)
- Leading contact (PE)
Yes
