Legrand 411953 411953 RCCB RCD (all types of current) 63 A 0.1 A 400 V
EAN:
Part number:
Item no:
Product type
RCCB
Number of pins
4
Differential current rating
0.1 A
Nominal current - rounded value
63 A
Nominal current
63 A
Datasheet (PDF)
Technical specifications
- Frequency: 50 Hz
- Product type
RCCB
- Number of pins
4
- Differential current rating
0.1 A
- Nominal current
63 A
- Nominal current - rounded value
63 A
- Dim
(W x H x D) 78.0000 x 101.0000 x 89.0000 mm
- Model
RCD (all types of current)
- Switch-off capacity
10 kA
- Content
1 pc(s)
- Nominal voltage
400 V
- Width
78.0000 mm
- Height
101.0000 mm
- Depth
89.0000 mm
- RoHS-compliant
Yes
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2155723 Legrand 411953 411953 RCCB RCD (all types of current) 63 A 0.1 A 400 V
User & Safety Instructions
User & Safety Instructions 2155723 Legrand 411953 411953 RCCB RCD (all types of current) 63 A 0.1 A 400 V
Description
Legrand TX3 residual current circuit breaker, type AS, for alternating and pulsating direct current according to VDE 066410, EN 610081, selective, delayed at least 40 ms, 4polig, rated current in 63 A, rated fault current IDN 100 mA, rated voltage UN 400 VAC, rated frequency 50 Hz, surge current resistant up to 3000 A, rated short-circuit current 10 kA at suitable pre-fuse, Mounting on top hat profile rail EN 60715 by snap-in quick attachments, clear information on the front of each device, clear switching position indicator red/green on the shift lever, with labeling window, with under-plug protection for the safe insertion of the conductor in the lift clamp, attachment of auxiliary devices possible.
