Leuze Electronic 50127220 Optical proximity sensor 1 pc(s) Max. range (open field): 120.000 mm
Product type
Optical proximity sensor
Max. range
120.000 mm
Type
50127220
Content
1 pc(s)
Laser category
2
EAN:
Part number:
Item no:
Technical specifications
- Product type
Optical proximity sensor
- Type
50127220
- Content
1 pc(s)
- Laser category
2
- Range (min.) (open area)
200 mm
120.000 mm
- Min. temperature
-5 °C
- Max. temperature
50 °C
- Manufacturer part #
50127220
- No. of pins
4
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3020375 Leuze Electronic 50127220 Optical proximity sensor 1 pc(s) Max. range (open field): 120.000 mm
Description
Preassembled with: Mounting plate; Light source: Laser; Protection class: 2; Measuring range: 200 ... 120,000 mm; absolute measurement accuracy: 2 mm; reproducibility (3 Sigma): 1.5 mm; travel speed max.: 10 m/s; supply voltage: 18 ... 30 V, DC; interface: PROFINET, SSI; connection: Circular plug, M12, 4-pin; dimensions: 84 mm x 166.5 mm x 159 mm; material housing: metal; display: LED, LC display; ambient temperature operation: -5 ... 50 °C; protection class IP 65
