Leuze Electronic 63000303 63000303 Door-operated safety switch side 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Door-operated safety switch
- Connection
Clamp
- Operation type
side
- Thread size
M20 x 1.5
- Material
Zamak
- Width
56 mm
- Type
63000303
- Content
1 pc(s)
- Dim
(W x H x D) 56 x 33 x 88 mm
- Height
33 mm
- Depth
88 mm
Slow-action switch
Metal
TRUE
Other
FALSE
None
Plug-in connection others
None
None
Cuboid
IP67
TRUE
Roller lever
None
FALSE
56 mm
33 mm
88 mm
FALSE
-25-80 °C
Roller cam straight
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2984035 Leuze Electronic 63000303 63000303 Door-operated safety switch side 1 pc(s)
Description
Contact configuration: 2NC + 1NO, creeping contact; cable entry: 3 pieces, M20 x 1.5; connection: Terminal, 6 -pin; Dimension: 56 mm x 33 mm x 88 mm; Material housing: metal, ZAMAK; switch type: interlocking device without locking, ISO 14119; switching direction: on both sides; one-sided; start-up operating directions: 4 x lateral (90°), 360°; protection class: IP 67; Approvals: IMQ, c UL US
