Manhattan 207850 2 ports HDMI splitter 4096 x 2160 p Black
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Manhattan 4-K bi-directional 2-Port HDMI Splitter/Switch 4K@30Hz manual selection passive (no power supply required), black
- Distributes a digital audio/video signal in 4K / UHD quality on two UHD HDMI displays or switches on a display between two sources to
- Hz-Auflosung 4K@30, 3D video and Deep Color
- Displays and sources, as well as splitter and switch function can be comfortably at the touch of a button switch
- Supports Video Amplifier bandwidth up to 340 MHz and 3.4 Gbit/s per channel (10.2 Gbit/s in total) for 4K x 2K-Displays
- It supports 36-bit Deep Color (12 bit per channel) and sYCC Color Space
Technical specifications
- 7.1 Surround sound
- Dolby TrueHD
- Product type
HDMI splitter
- Supported monitors
2
- No. of inputs
1 x
- Interfaces (input)
HDMI™
- No. of outputs
2 x
- Interfaces (output)
HDMI™
- Resolution (max.)
4096 x 2160 p
- Factory colour
Black
- Weight
100 g
- Width
52 mm
- Height
20 mm
- Depth
49 mm
- Dim
(W x H x D) 52 x 20 x 49 mm
- Port
2 ports
- Supported audio file formats
DTS
LPCM 7.1
- Version
Cable
- Type A
HDMI plug
- Type B
HDMI plug
- Cable use
TV/monitor
- Connection type
HDMI
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1888242 Manhattan 207850 2 ports HDMI splitter 4096 x 2160 p Black
User & Safety Instructions
User & Safety Instructions 1888242 Manhattan 207850 2 ports HDMI splitter 4096 x 2160 p Black
Description
The HDMI switch and HDMI Splitter in a
The bi-directional 4K 2-Port HDMI Splitter/Switch from Manhattan is the flexible 2-in-1 solution for your 4K-Applications: Distribute with the splitter function the signal of a video source on two displays, or turn off with the switch function between two video sources to play a display.
Excellent picture and sound quality plus easy installation
In case of image and sound quality, proceed with this splitter/switch multi-talent no compromises. 4K/UHD image signals are transmitted and the loss-free with 3D-support as well as audio in LPCM, DTS and Dolby TrueHD. The installation is very easy: Simply connect the HDMI cable (not included in the delivery) on the device and use it as desired. The power is supplied directly via the HDMI port, there is no need for external power supply. Further hardware or software configuration is not necessary.
This text is machine translated.
The bi-directional 4K 2-Port HDMI Splitter/Switch from Manhattan is the flexible 2-in-1 solution for your 4K-Applications: Distribute with the splitter function the signal of a video source on two displays, or turn off with the switch function between two video sources to play a display.
Excellent picture and sound quality plus easy installation
In case of image and sound quality, proceed with this splitter/switch multi-talent no compromises. 4K/UHD image signals are transmitted and the loss-free with 3D-support as well as audio in LPCM, DTS and Dolby TrueHD. The installation is very easy: Simply connect the HDMI cable (not included in the delivery) on the device and use it as desired. The power is supplied directly via the HDMI port, there is no need for external power supply. Further hardware or software configuration is not necessary.
This text is machine translated.
Features
- Total distance between the source and the splitter, as well as the splitter and the display: up to 5 m
- Positioning of the Shift key: Above (connects Port 1), at the bottom (connects Port 2)
- Power supply: 5V
- 1 x HDMI socket (input/output)
- 2 x HDMI socket (output/input)
- Input/Output Signal
- Video input signal: 0.5 - 1.0 V p-p
- DCC input signal: 5 V p-p (TTL)
- Maximum resolution of 3840×2160 Single-link Range: at 30 Hz and 4096 x 2160 at 24 Hz
- Video output, HDMI 1.4, HDCP 1.4
- Supported video resolutions
- DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p/4K@30Hz
- LED indicators: power supply and port connection
- Shift key
- Operating temperature: 0 °C - 40 °C
- Storage temperature: -20 to 60 °C
Scope of delivery
- 4K bi-directional 2-Port HDMI Splitter/Switch
- Quick guide
