1/3
Max Hauri 174027 Power strip Black, Anthracite CH plug 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Socket type: Type 13 (T13); USB 1x Type A + 1x Type C; RJ45 Cat 6a; HDMI
- Charging technology:standard 5 volt
- Number of slots: 2
- Feed: Plug connector can be mixed with AC166 and the market standard
- Cross section: 1.50 mm²
- USB Output Single A port: Max. 5.0 V / 10.0 W.
- USB Output Single C port: Max. 5.0 V / 15.0 W.
- USB output total: Type A+C: 5.0 V / 20.0 W.
- Suitable for panel thickness 1-30 mm
- Product type
Power strip
- Light bulb features
Child safety
incl. USB charging port
- Outlets
2
- Material
Aluminium
- Plug type
CH plug
- Factory colour
Black
Anthracite
- Length
266.5 mm
- Width
82 mm
- Height
86 mm
Documents & Downloads
Datasheet
Datasheet 3397034 Max Hauri 174027 Power strip Black, Anthracite CH plug 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3397034 Max Hauri 174027 Power strip Black, Anthracite CH plug 1 pc(s)
Description
PRISMA socket unit / profile black RAL9017, anthracite components RAL7035 / 2x type 13, 1x Charger USB-A 5/10W, 1x Charger USB-C 15W, 1x RJ45 CAT 6a, 1x HDMI 2.0 / adjustable mounting clamps / ALU/ connector mix. With market standard/ opening angle 90° with latching and automatic. Return
The high-quality PRISMA connection panels are the ideal mounting solution for the flexible office landscape and multi-used workplaces. When the power and multimedia connections are not in use, they can be elegantly covered by the rotating cover. As the mounting system and the cable duct are hidden, they can also be used aesthetically on glass tables. The mounting is done by means of adjustable clamps on table tops with a thickness of 1 to max. 30 mm. The modular design allows individual configurations of sockets, USB charging modules and multimedia connections.
• Cover the power and multimedia connections while not in use
• Hides mounting system and connecting cable
• Quick mounting without machining the tabletop
• Various configurations possible due to modular design
This text is machine translated.
The high-quality PRISMA connection panels are the ideal mounting solution for the flexible office landscape and multi-used workplaces. When the power and multimedia connections are not in use, they can be elegantly covered by the rotating cover. As the mounting system and the cable duct are hidden, they can also be used aesthetically on glass tables. The mounting is done by means of adjustable clamps on table tops with a thickness of 1 to max. 30 mm. The modular design allows individual configurations of sockets, USB charging modules and multimedia connections.
• Cover the power and multimedia connections while not in use
• Hides mounting system and connecting cable
• Quick mounting without machining the tabletop
• Various configurations possible due to modular design
This text is machine translated.
Features
- Mounting bracket
- Cover
- Cable can be tucked away
- Over current protection
- Child safety
