MD Micro Detectors Optical sensor DMR/0P-1H DMR/0P-1H 1 pc(s)
Product type
Optical sensor
Max. operating voltage
30 V DC
Connector
M12
Type
DMR/0P-1H
Min. operating voltage
10 V DC
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Opto sensor DMR/0P-1H
Technical specifications
- Weight: 28 g Approvals: , Ex, C UL US nominal sensing range Sn: 4,000 mm Output type: PNP no-load current: ≤ 330 mA Load current: ≤ 3 100 mA
- Product type
Optical sensor
- Type
DMR/0P-1H
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Outputs
PNP
- Connector
M12
- Enclosure material
Brass
- Material properties
nickel plated
4.000 mm
IP67
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- Content
1 pc(s)
- Switching frequency
250 Hz
Documents & Downloads
Datasheet
Datasheet 2273285 MD Micro Detectors Optical sensor DMR/0P-1H DMR/0P-1H 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2273285 MD Micro Detectors Optical sensor DMR/0P-1H DMR/0P-1H 1 pc(s)
Conformity certificate
Conformity certificate 2273285 MD Micro Detectors Optical sensor DMR/0P-1H DMR/0P-1H 1 pc(s)
Description
Scope of delivery
- Metal nut (x2)
- This text is machine translated.
Hints
For more information on this DMR/0P-1H, please refer to its datasheet under 'downloadable documents'
