MD Micro Detectors Optical sensor FFR3/BP-1E FFR3/BP-1E 1 pc(s)
Product type
Optical sensor
Max. operating voltage
30 V DC
Connector
M12
Type
FFR3/BP-1E
Min. operating voltage
10 V DC
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Opto sensor FFR3/BP-1E
Technical specifications
- Weight: 60 g
- Approvals: , Ex, Diversey, ECOLAB, cULus
- Nominal sensing range Sn:100 mm
- Output type: PNP
- Idling current: ≤ 335 mA (at Val=30V)
- Load current: 100 mA
- Product type
Optical sensor
- Type
FFR3/BP-1E
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Outputs
PNP
- Connector
M12
- Enclosure material
Stainless steel
- Material properties
rust-proof
100 mm
- Min. temperature
-25 °C
- Max. temperature
+80 °C
- Content
1 pc(s)
- Switching frequency
500 Hz
Documents & Downloads
Datasheet
Datasheet 2273326 MD Micro Detectors Optical sensor FFR3/BP-1E FFR3/BP-1E 1 pc(s)
Datasheet 2273326 MD Micro Detectors Optical sensor FFR3/BP-1E FFR3/BP-1E 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2273326 MD Micro Detectors Optical sensor FFR3/BP-1E FFR3/BP-1E 1 pc(s)
Conformity certificate
Conformity certificate 2273326 MD Micro Detectors Optical sensor FFR3/BP-1E FFR3/BP-1E 1 pc(s)
Description
Scope of delivery
- Metal nut (2x)
- This text is machine translated.
Hints
For more information on this FFR3/BP-1E, please refer to its datasheet under 'downloadable documents'
