MD Micro Detectors Reflective light barrier FC6I/0B-0806-1F FC6I/0B-0806-1F 1 pc(s)
Product type
Reflective light barrier
Max. operating voltage
24 V DC
Connector
M8
Type
FC6I/0B-0806-1F
Min. operating voltage
12 V DC
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
FORK LIGHT BARRIER FC6I/0B-0806-1F
Technical specifications
- Weight: 90 g
- Approval UL.
- Nominal sensing range Sn: 80 mm
- Output type: NPN + PNP
- Idle current: 40 mA
- Load current: 100 mA
- Product type
Reflective light barrier
- Type
FC6I/0B-0806-1F
- Min. operating voltage
12 V DC
- Max. operating voltage
24 V DC
- Operating voltage
12 - 24 V DC
- Connector
M8
- Enclosure material
Aluminium
- Material properties
painted
80 mm
IP65
- Content
1 pc(s)
- Switching frequency
15 kHz
Documents & Downloads
Datasheet
Datasheet 2273318 MD Micro Detectors Reflective light barrier FC6I/0B-0806-1F FC6I/0B-0806-1F 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2273318 MD Micro Detectors Reflective light barrier FC6I/0B-0806-1F FC6I/0B-0806-1F 1 pc(s)
Description
Hints
For more information on this FC6I/0B-0806-1F, please refer to its datasheet under 'downloadable documents'
