MD Micro Detectors Sensor Inductive PFM1/BP-4H PFM1/BP-4H PNP
Product type
Sensor
Max. operating voltage
30 V DC
Switching distance (max.)
8 mm
Outputs
PNP
Model
Inductive
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
INDUCTIVE SENSOR PFM1/BP-4H
Technical specifications
- Weight: 30 g
- Approvals: cULus
- Nominal sensing range Sn: 8 mm
- Output type: PNP
- No-load current ≤ 315 mA
- Load current ≤ 3 200 mA
- Product type
Sensor
- Type
PFM1/BP-4H
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Switching frequency
2 kHz
- Switching distance (max.)
8 mm
- Outputs
PNP
- Enclosure material
Stainless steel
- Model
Inductive
- Material properties
rust-proof
- Connector
M12
- Min. temperature
-40 °C
- Max. temperature
+80 °C
- Content
1 pc(s)
- Switching frequency
2 kHz
Documents & Downloads
Datasheet
Datasheet 2273214 MD Micro Detectors Sensor Inductive PFM1/BP-4H PFM1/BP-4H PNP
Datasheet 2273214 MD Micro Detectors Sensor Inductive PFM1/BP-4H PFM1/BP-4H PNP
User & Safety Instructions
User & Safety Instructions 2273214 MD Micro Detectors Sensor Inductive PFM1/BP-4H PFM1/BP-4H PNP
Conformity certificate
Conformity certificate 2273214 MD Micro Detectors Sensor Inductive PFM1/BP-4H PFM1/BP-4H PNP
Description
Scope of delivery
- 2 Mounting nut M12x1
