MD Micro Detectors Ultrasonic sensor UQ1C/G7-0E UQ1C/G7-0E 1 pc(s)
Product type
Ultrasonic sensor
Max. operating voltage
30 V DC
Connector
M12
Type
UQ1C/G7-0E
Min. operating voltage
10 V DC
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
ULTRASONIC SENSOR UQ1C/G7-0E
- Approvals: cULus
- Nominal sensing range Sn: 800 mm
- Output type: PNP + 0...10 V.
- No-load current: ≤ 335 mA
- Load current: 100 mA
- This text is machine translated.
Technical specifications
- Approvals: cULus
- Nominal sensing range Sn: 800 mm
- Output type: PNP + 0...10 V.
- No-load current: ≤ 335 mA
- Load current: 100 mA
- Product type
Ultrasonic sensor
- Type
UQ1C/G7-0E
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Outputs
PNP
- Connector
M12
800 mm
IP67
- Min. temperature
-20 °C
- Max. temperature
+70 °C
- Content
1 pc(s)
- Switching frequency
5 Hz
Documents & Downloads
Datasheet
Datasheet 2273401 MD Micro Detectors Ultrasonic sensor UQ1C/G7-0E UQ1C/G7-0E 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2273401 MD Micro Detectors Ultrasonic sensor UQ1C/G7-0E UQ1C/G7-0E 1 pc(s)
Conformity certificate
Conformity certificate 2273401 MD Micro Detectors Ultrasonic sensor UQ1C/G7-0E UQ1C/G7-0E 1 pc(s)
Description
Scope of delivery
- 1 ghera M18x1
- This text is machine translated.
Hints
For more information on this UQ1C/G7-0E, please refer to its datasheet under 'downloadable documents'
