MD Micro Detectors Ultrasonic sensor UT1B/G6-1ESY UT1B/G6-1ESY 1 pc(s)
Product type
Ultrasonic sensor
Max. operating voltage
30 V DC
Connector
M12
Type
UT1B/G6-1ESY
Min. operating voltage
10 V DC
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
ULTRASONIC SENSOR UT1B/G6-1ESY
Technical specifications
- Weight: 215 g
- Approvals: cULus
- Nominal sensing range Sn: 3500 mm
- Output type: PNP+ 4...20 mA
- Idle current: 25 mA
- Load current: 100 mA
- Product type
Ultrasonic sensor
- Type
UT1B/G6-1ESY
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Outputs
PNP
- Connector
M12
- Enclosure material
Steel
3500 mm
IP67
- Min. temperature
-20 °C
- Max. temperature
+70 °C
- Content
1 pc(s)
- Switching frequency
1 Hz
Documents & Downloads
Datasheet
Datasheet 2273405 MD Micro Detectors Ultrasonic sensor UT1B/G6-1ESY UT1B/G6-1ESY 1 pc(s)
Datasheet 2273405 MD Micro Detectors Ultrasonic sensor UT1B/G6-1ESY UT1B/G6-1ESY 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2273405 MD Micro Detectors Ultrasonic sensor UT1B/G6-1ESY UT1B/G6-1ESY 1 pc(s)
Description
Scope of delivery
- 2 x M30x1.5 washer
- This text is machine translated.
Hints
For more information on this UT1B/G6-1ESY, please refer to its datasheet under 'downloadable documents'
