MEAN WELL DPB09W8-05 DC/DC converter 0.800 A 9 W Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- REMOTE Function
- Product type
DC/DC converter
- Type
DPB09W8-05
- Max. output current
0.800 A
- Output current (max.) - rounded
800 mA
9 W
- Enclosure
SIP 8
- Dim
(L x W x H) 24 x 9.6 x 11.2 mm
- Height
11.2 mm
- Length
24 mm
- Width
9.6 mm
- RoHS-compliant
Yes
- Output voltage (max.)
5 V
- Output voltage (min.)
-5 V
- Output current (min.)
-0.800 A
- Weight
5 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3556660 MEAN WELL DPB09W8-05 DC/DC converter 0.800 A 9 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3556660 MEAN WELL DPB09W8-05 DC/DC converter 0.800 A 9 W Content 1 pc(s)
Description
The series DPB09W8 is an insulated and regulated DC/DC converter with 9 W in the SIP8-casing. They have international standard pins, a high degree of efficiency of up to 87%, a wide operating temperature range of -40-+90'C, 1.5KVdc I/P-O/P isolation voltage, continuous short-circuit protection, etc. The models take into account various 9-75Vdc 8:1 ultra wide input voltages, and various output voltages, +-5V/+-12V/+-15V for dual outputs suitable for all types of systems, such as industrial control, telecommunications, distributed power architecture, and so on.
