MEAN WELL MPM-30-3.3 AC/DC PSU (print) 3.3 V DC 6 A
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Medical Encapsulated Single Output Power: 30 W
- Output 3.3 V DC / 6 A
- Solder pins, Print
Technical specifications
- Product type
AC/DC PSU (print)
- Input voltage (max.)
264 V AC
- Max. output current
6 A
- Output current (max.) - rounded
6 A
- Min. input voltage
80 V AC
- Dim
(L x W x H) 69.5 x 39 x 24 mm
- Output voltage (max.)
3.3 V DC
- Connection
Solder pins
Print
- Input frequency
47-63 Hz
- Efficiency to
82,5 %
- Tolerance (output voltage)
±2,0 %
- Protection class
II
- No. of outputs
1 x
- Type
1
- Output voltage 1
3.3 V DC
- Output current 1
6 A
- Operating temperature (max.)
85 °C
- Operating temperature (min.)
-40 °C
- Weight
102 g
- Insulation voltage
4000 V AC
- Type
Pulsed
- Width
39 mm
- Height
24 mm
- Length
69.5 mm
- Residual ripple
80 mVp-p
- Type
MPM-30-3.3
- UKCA
yes
Compliance & Certifications
Certified by EU Garan
Documents & Downloads
Datasheet
Datasheet 1838197 MEAN WELL MPM-30-3.3 AC/DC PSU (print) 3.3 V DC 6 A
User & Safety Instructions
User & Safety Instructions 1838197 MEAN WELL MPM-30-3.3 AC/DC PSU (print) 3.3 V DC 6 A
Warranty Terms
Warranty Terms 1838197 MEAN WELL MPM-30-3.3 AC/DC PSU (print) 3.3 V DC 6 A
Description
Mean corrugated represents a new power supply series with high power density: in closed design for PCB mounting the series MPM. Compared with the size of the last generation-PM AND NFM-is the size of the new series only one-third, but a wider operating temperature range, a higher efficiency and lower idle power. The design of this series meets the guidelines of the IEC/EN 60601-1 of 3. Version and ANSI/AAMI IT 60601-1, meets the requirements of 2x mop and has a low leakage current (<80 μA). It is approved for medical equipment. The level the BF with direct patient contact. Suitable applications include medical test devices, portable medical devices and medical devices, which require an extremely low standby power consumption, etc.
This text is machine translated.
This text is machine translated.
Features
- Closed design, PCB mounting
- Universal input
- Overload protection by switching off, auto recovery
- Protected against short circuit, overload, overvoltage, overheating
- Insulation category II
- Conforms to EN 60601-1
- Low idle power
