MEAN WELL SCWN03W8-15 DC/DC converter 24 V 15 V 0.200 A 3 W Content 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Product type
DC/DC converter
- Type
SCWN03W8-15
- Nominal voltage
24 V
- Min. input voltage
9 V
- Input voltage (max.)
75 V
- Output voltages
15 V
- Max. output current
0.200 A
- Output current (max.) - rounded
200 mA
3 W
- Enclosure
DIP 24
- Operating temperature (min.)
-40 °C
- Operating temperature (max.)
95 °C
- Dim
(L x W x H) 31.8 x 20.3 x 10.2 mm
- Height
10.2 mm
- Length
31.8 mm
- Width
20.3 mm
- RoHS-compliant
Yes
- Weight
12.5 g
- Content
1 pc(s)
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3556696 MEAN WELL SCWN03W8-15 DC/DC converter 24 V 15 V 0.200 A 3 W Content 1 pc(s)
Description
The SCWN03W8 series are isolated and regulated 3W DC/DC converter modules in the DIP24 package. They are characterized by pinning according to international standard, a high degree of efficiency of up to 84%, a large operating temperature range of -40 to +95 °C, an insulation voltage of 3 kVdc between input and output, compliance with the BS EN/EN55022 standard (radiation class B) without additional components, short-circuit protection in continuous operation, an extremely wide input range of 8:1 (9 to 75 V) and various output voltages of 3.3 V/5 V/12 V/15 V for one output off. They are suitable for all types of systems, e.g. in industrial control, telecommunications, distributed power supply architectures, etc.
