MEAN WELL SPAN02W8-03 DC/DC converter 3.3 V 0.500 A 2 W Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- REMOTE Function
- Product type
DC/DC converter
- Type
SPAN02W8-03
- Output voltages
3.3 V
- Max. output current
0.500 A
- Output current (max.) - rounded
500 mA
2 W
- Enclosure
SIP 8
- Dim
(L x W x H) 21.8 x 9.2 x 11.1 mm
- Height
11.1 mm
- Length
21.8 mm
- Width
9.2 mm
- RoHS-compliant
Yes
- Weight
4.8 g
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 3556675 MEAN WELL SPAN02W8-03 DC/DC converter 3.3 V 0.500 A 2 W Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3556675 MEAN WELL SPAN02W8-03 DC/DC converter 3.3 V 0.500 A 2 W Content 1 pc(s)
Description
The SPAN02W8 series are insulated and regulated 2W DC/DC converters in modular design in SIP8 casing. They have an international standard pinning, a high degree of efficiency of up to 83%, a wide operating temperature range of -40-+95°C, 3Vdc I/P-O/P isolation voltage, compliance with BS EN/EN55022 Radiation class A without additional components, overload and short-circuit protection, etc. The models have an ultra-wide input range of 9-75Vdc, 8:1 input voltage ratio and various output voltages, 3.3V/5V/12V/15V, which are suitable for all types of systems, such as industrial controls, telecommunications, distributed power architectures, etc.
