MENNEKES 25405 25405 Multimedia switchgear Screw fastening Content 1 pc(s)

MENNEKES industrial media distributor housing 520 x 225mm protection IP44 lower part black upper part electrogray RAL 7035 laterally hinged on right with transparent actuation flap without touch protection (10 TE) Mounting plate with patch field made of stainless steel for snapping in 8 manufacturer-independent RJ45 keystones (not included in delivery) and threaded bolts M6 for optimal connection of an external earth conductor Keystone-recesses according to IEC 60603-7: Approx. 19.45 x 14.91mm 1 Cepex data socket black (RAL 9005) with 2x RJ45 angle coupling modules Installation room for network components (Switch, W-LAN access point, router, etc.): Approx. 200 x 165 x 95mm (LxWxH) 4 x hook and loop fasteners for mounting of built-in components on the bottom plate 2 Schuko sockets for the voltage supply of integrated active components Cable screw set enclosed: 2x screw connection M 40, 2x multi seal with 6 openings for a cable diameter of 6-9mm incl. 5 blind plugs 1x screw joint M 20 AMAXX Mounting set consisting of: - 4x screw 6x70mm - 4x universal double 8x50mm

This text is machine translated.
