MENNEKES 94550SI CEE socket combo 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Contact material: CuSn
- Military version: No.
- Surface treatment contacts: Untreated
- CEE socket - 16 A: 1x16A5p400V
- CEE socket - 32 A: Without
- CEE socket - 63 A: Without
- CEE socket - 125A: Without
- Number of earthed sockets CEE 7/3 (type F): 3
- Security: Other
- Residual current type: Other
- FI-Safety switch: Other
- Housing material: Plastic
- Feed/connection options: 1 line (stub cable)
- Handling: Portable
- Product type
CEE socket combo
IP44
- Factory colour
Silver
- Dim
(W x H x D) 250 x 406 x 195 mm
- Width
250 mm
- Height
406 mm
- Content
1 pc(s)
- Depth
195 mm
Documents & Downloads
Datasheet
Datasheet 3855600 MENNEKES 94550SI CEE socket combo 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3855600 MENNEKES 94550SI CEE socket combo 1 pc(s)
Description
MENNEKES AIRKRAFT Ready wired for connection Protection type IP 44 Housing: 1 AMAPLAST housing black (similar to RAL 9005) and hinged device cover (silver) Safety under transparent actuation flap Mounting:/Security: Pos.01 1 CEE-socket 16A 5p 400V Pos.02 3 Safety contact sockets 16A 2p+E 230V (11012) without safety Cable entries: at the top, for breaking off 1x M32, 1x M25, 2x M20 1x feedthrough for compressed air connection sideways locked for breaking off 1x M25 including Mounting eyelets (102070)
