MENNEKES 970001GE CEE socket combo 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Contact material: CuSn
- Military version: No.
- Surface treatment contacts: Untreated
- CEE socket - 16 A: 1x16A5p400V
- CEE socket - 32 A: 1x32A5p400V
- CEE socket - 63 A: Without
- CEE socket - 125A: Without
- Number of earthed sockets CEE 7/3 (type F): 4
- Protection: LS-switch
- Residual current type A
- FI-circuit breaker: FI with IFN 0.03 A (standard)
- Housing material: Plastic
- Feed/connection options: 1 line (stub cable)
- Type of mains connection: Other
- Handling: Dependent
- Product type
CEE socket combo
IP44
- Factory colour
Yellow
- Dim
(W x H x D) 225 x 370 x 330 mm
- Width
225 mm
- Height
370 mm
- Content
1 pc(s)
- Depth
330 mm
Documents & Downloads
Datasheet
Datasheet 3855106 MENNEKES 970001GE CEE socket combo 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3855106 MENNEKES 970001GE CEE socket combo 1 pc(s)
Description
MENNEKES socket combination AMAXX dependent upon connection ready wired Protection class IP 44 Housing: 1 AMAPLAST casing 260x225 mm (HxB) Lead-sealable with suspension eyes on top, grip hooks on the bottom and enclosed chain set enclosure frames black enclosure cover parts yellow laterally hinged with double thread cover screws Security on prelockable mounting rails under transparent operating flaps Opening downwards and with padlock Sockets lockable plug-in general Mounting/security: Pos.01 1 CEE socket 32A 5P 400V 1 LS switch 32A 3P C Pos.02 1 CEE socket 16A 5P 400V 1 LS switch 16 3P C Pos.03 4 safety sockets 16A 2P+E 230V 4 LS-switch 16A 1P C Pos.0103 1 FI-circuit breaker 40A 4P IFN = 0.03A line entry/connection possibility: 1 M 32 top (closed) 1 M 25 top (closed) 1 M 20 top (closed) for a cable up to 5 x 10 mm² RDF=0.5
