MENNEKES CEE power distributor 95471
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Contact material: CuSn
- Military version: No.
- Surface treatment contacts: Untreated
- CEE socket - 16 A: 1x16A5p400V
- CEE socket - 32 A: Without
- CEE socket - 63 A: Without
- CEE socket - 125A: Without
- Number of earthed sockets CEE 7/3 (type F): 1
- Security: Other
- Residual current type A
- FI-circuit breaker: FI with IFN 0.03 A (standard)
- Housing material: Plastic
- Feed/connection options: 1 line (stub cable)
- Handling: Wall-mounting
- Product type
CEE power distributor
IP44
- Factory colour
Grey
- Dim
(W x H x D) 110 x 410 x 100 mm
- Width
110 mm
- Height
410 mm
- Content
1 pc(s)
- Depth
100 mm
Documents & Downloads
Datasheet
Datasheet 3856474 MENNEKES CEE power distributor 95471
User & Safety Instructions
User & Safety Instructions 3856474 MENNEKES CEE power distributor 95471
Description
MENNEKES socket strip wired ready for connection Protection class IP 44 Housing: 1 PA housing 408x97x60 mm (LxWxH) electro gray RAL 7035 activation flap on upper section Mounting/security: Pos.01 1 CEE socket 16A 5p 400V Pos.02 1 CEE socket 16A 3p 230V pos.03 1 safety socket (type F) 16A 2p+E 230V pos.0103 1 FI-circuit breaker 40A 4p IFN=0.03A line input/connection: 1 M 25 sealed 1 M 25 with screw connection (supplied) for 1 cable up to 5 x 2.5 mm² with internal strain relief 1 bracket (loose)
