Buy Metrel 20993213 A 1532 XA Adapter 1 pc(s)

A black and blue electronic measuring device with an attached cable and plug, used for diagnosing electric vehicles.

Datasheet (PDF)

13 Piece(s)

Do your needs go beyond this?

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 626.05 / piece)

€

Report legal concerns

Technical specifications

Height: 100 mm

Length: 200 mm

Width: 70 mm

Type: A 1532 XA

Weight: 900 g

Product type: Adapter

Documents & Downloads

Datasheet

Datasheet 2536241 Metrel 20993213 A 1532 XA Adapter 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2536241 Metrel 20993213 A 1532 XA Adapter 1 pc(s)

Description

The adapter A 1532 EVSE XA is suitable for electrical safety and functional tests of EVSEs together with the supported METREL system testers. It is designed for testing Mode 3 EV power supplies with a Type 2 connector. The XA version supports three-phase load tests up to 13A and various types of errors, including PE open. With the help of the Metrel AutoSequences®, which are predefined in the newer multifunction testers, the complete EVSE charging station (step by step) can be tested both electrically and functionally by pressing a button. With MESM, you can create a professional station-based report.

This text is machine translated.

Features

e-MobilityRenewable power and car chargingEVSE design and testingEVSE measurements Proximity Pilot 0–64Control pilot gives line impedance settings for charging stationFault loop impedance for charging stationProximity sensor function checkControl pilot operational checkInsulation test for charging station1-phase charging station test1-phase test by socket3-phase charging station testDiode short-fault simulationPE open error simulationCP short-fault simulation (status E)Load test up to 13 A.AUTO SEQUENCE EVSEBanana jack outputs for connection to a three-phase system tester;Voltage display at the EVSE output;Proximity pilot resistor selector for simulating the presence of EV cables and detecting the rated current;Selector switch for the Control Pilot resistor to simulate the condition of an electric vehicle;Socket output for connection to a single-phase system tester (phase 1, neutral, PE);Type 2 connector for the EVSE connection;6mA EV RCD support;Support for functional testing;Support for EVSE AUTO SEQUENCE®Generate MESM reportsLoad tests with up to 13A on socket – single phase or banana sockets – three phase;Fault simulation of diode short circuit, PE-CP short circuit and PE open; BNC output connector for CP signal monitoring.Building NS installationEISasp competencies: Safety inspection of electrical low-voltage installationsEISC competencies: Safety of low-voltage electrical installations for contractors and maintenance personnelIEC/EN 61557 Electrical safety in low-voltage networks up to 1 000 V AC and 1 500 V DC - Devices for testing, measuring or monitoring protective measures - SeriesEquipment for supplying electric vehiclesEVSE competencies: Safety of electrical vehicle supply equipmentIEC/EN 61851 conductive charging system for electric vehicles
