Metz Connect 1309A0-I RJ45 module E-DAT CAT 6 1 pc(s)
EAN:
Part number:
Item no:
Number
Total (€ 12.60 / piece)
€
Highlights & Details
E-DAT module coupling 8(8) 180° class EA
- 2 installation forms in a coupling
Technical specifications
- Compatible with
E-DAT
- Product type
RJ45 module
CAT 6
- Mating direction
180°
- Tool-free installation
Yes
- Factory colour
Silver (metallic)
- Weight
0.03
Variants(All information is without VAT, plus shipping costs)
Mating direction
Metz Connect 1309A0-I RJ45 module E-DAT CAT 6 1 pc(s)
This article
180°
Minimum order quantity: 1
Multiple: 1
€ 12.60*
Metz Connect 1309A1-I RJ45 module E-DAT CAT 6 1 pc(s)
90°
Minimum order quantity: 1
Multiple: 1
€ 12.60*
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 986522 Metz Connect 1309A0-I RJ45 module E-DAT CAT 6 1 pc(s)
User & Safety Instructions 986522 Metz Connect 1309A0-I RJ45 module E-DAT CAT 6 1 pc(s)
Description
RJ45 cable coupling class E, compliance with class E, A according to ISO/IEC 11801, DIN EN 50173-1 suitable for 10GBit Ethernet (IEEE 802.3an), Remote Power (PoE, PoE plus and UPoE) and HDBaseT, fully shielded 180° coupling made of die-cast zinc, refined, especially suitable for Consolidation Points and Cross-Connect cabling, 2 designs in one coupling, For installation in module or keystone applications
This text is machine translated.
This text is machine translated.
Features
- Class E/CAT.6 Link
- Suitable for Power over Ethernet (PoE and PoE plus)
- Fully-shielded 180° clutch made of die-cast zinc, refined
- Particularly suitable for consolidation points and cross-connect wiring
- 2 installation forms in a coupling, for installation in module or keystone applications
- For 180° version matching module applications: Module connection box 1-, 2-, and 3-Port, 19" module carrier 24 and 48 Port, Module 3, 4, 6, 8, 12 and 16 he AP housing, Subway underground units, E-DAT module REG and industry IP67 V6 Attachments
Hints
The plastic insert served on the picture for leadership of the contacts. This guide is as a result of the contact record change is no longer necessary.
