Digitus DN-93615 RJ45 module Keystone CAT 6A 1 pc(s)
EAN:
Part number:
Item no:
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 2.93
5
5% = € 0.15
€ 2.78
10
8% = € 0.22
€ 2.71
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 2.93 / piece)
€ 5.87
-50 %
€
Highlights & Details
CAT 6A Keystone Module, shielded, toolfree
- Quick and safe wire terminations without any special tool
Technical specifications
- Compatible with
Keystone
- Product type
RJ45 module
CAT 6A
- Tool-free installation
Yes
- Cable length
0.014 m
- Version
Adapter
- Cable use
Networks
- Weight
21.00
Variants(All information is without VAT, plus shipping costs)
Digitus DN-93615 RJ45 module Keystone CAT 6A 1 pc(s)
This article
Minimum order quantity: 1
Multiple: 1
€ 2.93*
Digitus DN-93615-24 RJ45 module Keystone CAT 6A
Minimum order quantity: 1
Multiple: 1
€ 58.82*
Documents & Downloads
Datasheet
Datasheet 1431384 Digitus DN-93615 RJ45 module Keystone CAT 6A 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1431384 Digitus DN-93615 RJ45 module Keystone CAT 6A 1 pc(s)
Information
Information 1431384 Digitus DN-93615 RJ45 module Keystone CAT 6A 1 pc(s)
Certificate
Certificate 1431384 Digitus DN-93615 RJ45 module Keystone CAT 6A 1 pc(s)
Description
The Item "DN-93615" of the brand DIGITUS® is a shielded CAT 6A Keystone Module with tool free installation which provides best performance and link quality for your network. The compact design allows the installation of 24 pieces in a row of 483 mm (19") 1U panels. It is conform to Category 6A / 10GBase-T Channel, ANSI/EIA/TIA 568C.2.1 :2002, ISO/IEC 11801:2002.
· Transmission properties: Category 6A, Class EA
· Area of application: Up to 500 MHz, 10GBase-T
· Norms: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C, 802.3af, 802.3at PoE+
· General properties:
· Suitable for patch panels and mounting outlets
· RJ45 female, 8P8C
· Cable installation via LSA strips, color coded according to EIA/TIA 568 A & B
· Cable fixing with cable tie
· Tool-free installation
· 360° shield coverage
· Dust cover included
· Technical properties:
· Housing material: Zinc die-cast, nickel-plated
· RJ45 female material: ABS UL 94V-0
· RJ45 female contact: Tinned phosphor bronze, 0.5 ? gold-plated contact
· RJ45 shielding: Tinned bronze
· LSA termination clamp: Krone LSA+, UL 94V-2, zinc plated phosphor bronze
· Conductor plate: FR4, UL 94V-0
· Physical properties:
· Insertion force: 30N max. (IEC 60603-7-5)
· Retention strength: 7.7 kg between jack and plug
· Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
· Mating cycles female: > 750 acc. to ISO/IEC 11801, IEC 60603-7-5
· Clamp: > 200 acc. to ISO/IEC 11801, IEC 60603-7-5
· IDC wire size: 22 – 26 AWG solid and stranded conductor
· Insulation resistance: > 500 MOhm
· Contact resistance: < 20 MilliOhm
· Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground)
· Transmission properties: Category 6A, Class EA
· Area of application: Up to 500 MHz, 10GBase-T
· Norms: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C, 802.3af, 802.3at PoE+
· General properties:
· Suitable for patch panels and mounting outlets
· RJ45 female, 8P8C
· Cable installation via LSA strips, color coded according to EIA/TIA 568 A & B
· Cable fixing with cable tie
· Tool-free installation
· 360° shield coverage
· Dust cover included
· Technical properties:
· Housing material: Zinc die-cast, nickel-plated
· RJ45 female material: ABS UL 94V-0
· RJ45 female contact: Tinned phosphor bronze, 0.5 ? gold-plated contact
· RJ45 shielding: Tinned bronze
· LSA termination clamp: Krone LSA+, UL 94V-2, zinc plated phosphor bronze
· Conductor plate: FR4, UL 94V-0
· Physical properties:
· Insertion force: 30N max. (IEC 60603-7-5)
· Retention strength: 7.7 kg between jack and plug
· Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
· Mating cycles female: > 750 acc. to ISO/IEC 11801, IEC 60603-7-5
· Clamp: > 200 acc. to ISO/IEC 11801, IEC 60603-7-5
· IDC wire size: 22 – 26 AWG solid and stranded conductor
· Insulation resistance: > 500 MOhm
· Contact resistance: < 20 MilliOhm
· Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground)
Features
- Case material: die-cast zinc-plated
- Contact material: Phosphorbronze
- 360° contact of the cable shield for improved EMC protection
- Coating Contacts: Nickel, gold-plated 0.5 μ
- Operating temperature: -10 °C ~ +60 °C (ISO/IEC 11801, ANSI/TIA/EIA 568B.2)
- Material pcb: FR4, UL 94 V-0, 1.45 mm thick
- Mating cycles: ≥ 750 (ISO/IEC 11801, IEC 60603-7-5)
- Cu wire diameter: AWG (26... 22), flexible and solid
- RJ45 connector for patch panel mounting
- Compact design allows series installation of 24 pieces in 483 mm (19") 1 HE panels
- Opening dimension in accordance with Keystone Standard 19.35 mm x 14.8 mm
- Suitable for combination with design covers from well-known manufacturers of switch material such as Busch-Jaeger
- Suitable for combination with design covers of switch material PEHA
- Suitable for combination with design covers of switch material FELLER (CH) EDIZIOdue
- By short design Simple assembly in bottom tanks, surface-caps, distributor fields and table housings
- The IEEE 802.3at POE+ ensprechend
- Meets the requirements according to IEC 60603-7-51, ANSI/TIA/EIA 568-C.2, IEC 60512-27-100, ISO/IEC 11801. 2.
- Size (HXWXD): 20.1 4.34 mm
