Digitus DN-91410 24 ports Network patch panel 483 mm (19") Unequipped 1 U Unequipped
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 12.60 / piece)
€
Highlights & Details
Modular Patch Panel, 24-port
- Patch panel for Keystone module
- Shielded
Technical specifications
- Grey (RAL 7035)
- Product type
Network patch panel
- Rack size
483 mm (19")
Unequipped
- Rack unit
1 U
- Port
24 ports
- Patch panel design
Unequipped
- Connection method
Keystone module
- Connections
24 LAN ports
- Width
483 mm
- Height
44 mm
- Weight
0.87
Documents & Downloads
Datasheet
Datasheet 1418850 Digitus DN-91410 24 ports Network patch panel 483 mm (19") Unequipped 1 U Unequipped
User & Safety Instructions
User & Safety Instructions 1418850 Digitus DN-91410 24 ports Network patch panel 483 mm (19") Unequipped 1 U Unequipped
Description
· Layout Keystone Entry: Straight
· Area of application: 19" cabinet
· Norms: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C
· General properties:
· Suitable for 483 mm (19") cabinet mounting
· Suitable for shielded Digitus® Keystone Modules and Couplers
· Central ground connection
· Technical properties:
· Housing material: 1.5 mm SPCC cold rolled stell sheet, powder-coated
· Material standard: EN 10 130(1991), BS 1449, NFA 36/401, DIN 1623, UNI 5866, UNE 36-086, SIS, JIS G 3141, ASTM, SAE
· Grounding bar material: Galvanized steel
· Grounding wire: 18 AWG, 40 cm
· Physical properties:
· Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
· Area of application: 19" cabinet
· Norms: ISO/IEC 11801 2nd Ed., EN 50173-1, EIA/TIA 568-C
· General properties:
· Suitable for 483 mm (19") cabinet mounting
· Suitable for shielded Digitus® Keystone Modules and Couplers
· Central ground connection
· Technical properties:
· Housing material: 1.5 mm SPCC cold rolled stell sheet, powder-coated
· Material standard: EN 10 130(1991), BS 1449, NFA 36/401, DIN 1623, UNI 5866, UNE 36-086, SIS, JIS G 3141, ASTM, SAE
· Grounding bar material: Galvanized steel
· Grounding wire: 18 AWG, 40 cm
· Physical properties:
· Operation temperature: -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)
Features
- Material housing: SPCC, 1.0 mm kaltgewalzter C-steel according to JIS G 3141-1996
- Suitable for 483 mm (19") cabinet installation
