Molex 702472054 Pin strip low type Contact spacing: 2.54 mm Total number of pins: 20 No. of rows: 2 1 pc(s) Tray
EAN:
Part number:
Item no:
Packaging type
Tray
Product type
Pin strip
CS
2.54 mm
No. of rows
2
Pins per row
10
Datasheet (PDF)
Highlights & Details
Molex 702472054 RA SHROUDED HDR C-GR
- Total number of pins 20
- No. of rows 2
- Content 1 pc(s)
Our service for you
Technical specifications
- Packaging type
Tray
- Product type
Pin strip
- Features
low type
- CS
2.54 mm
- No. of rows
2
- Pins per row
10
- Total number of pins
20
- Content
1 pc(s)
- Type
702472054
- Connector coating thickness
0.127 µm
- Manufacturer part #
702472054
- Board contact surface
Tin plated
- Connector contact surface
Gold
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Engineering Series Name
RA SHROUDED HDR C-GR
- Engineering Series No
70247
Documents & Downloads
Datasheet
Datasheet 2760404 Molex 702472054 Pin strip low type Contact spacing: 2.54 mm Total number of pins: 20 No. of rows: 2 1 pc(s) Tray
User & Safety Instructions
User & Safety Instructions 2760404 Molex 702472054 Pin strip low type Contact spacing: 2.54 mm Total number of pins: 20 No. of rows: 2 1 pc(s) Tray
Description
2.54mm Pitch C-Grid Header, Low Profile, Dual Row, Right Angle, Shrouded, 20 Circuits, 0.127µm Gold (Au) Plating, Tin(Sn) PC Tail Plating
