Molex Built-in SIL socket (standard) Total number of pins 16 1724470216 1 pc(s) Tray
EAN:
Part number:
Item no:
Product type
Built-in SIL socket (standard)
Connector type
Power strip
No. of rows
2
Total number of pins
16
Packaging type
Tray
Datasheet (PDF)
Highlights & Details
Molex 1724470216 MiniFit Jr Vert Hdr
- Content: 1 pc(s)
- No. of rows: 2
- Total number of pins: 16
Our service for you
Technical specifications
- Packaging type
Tray
- Product type
Built-in SIL socket (standard)
- Connector type
Power strip
- No. of rows
2
- Pins per row
8
- Total number of pins
16
- Content
1 pc(s)
- Case material
Polyamide 6.6
- Manufacturer part #
1724470216
- Insulation material
Polyamide 6.6
- Board contact surface
Tin plated
- Connector contact surface
Tin plated
- RoHS-compliant
Yes
- Connector orientation
Perpendicular (to the PCB)
- Type
1724470216
- Engineering Series Name
MiniFit Jr Vert Hdr
- Engineering Series No
172447
Documents & Downloads
Datasheet
Datasheet 2760274 Molex Built-in SIL socket (standard) Total number of pins 16 1724470216 1 pc(s) Tray
User & Safety Instructions
User & Safety Instructions 2760274 Molex Built-in SIL socket (standard) Total number of pins 16 1724470216 1 pc(s) Tray
Description
Mini-Fit Jr. Header, Dual Row, Vertical, without Snap-in Plastic Peg PCB Lock, 16 Circuits, PA Polyamide Nylon 6/6 94V-2, Tin (Sn) Plating, Glow-Wire Capable
