Image similar
Molex Pin housing PCB Total number of pins 4 Contact spacing: 3.18 mm 438100100 1 pc(s) Tray
EAN:
Part number:
Item no:
Product type
Pin housing PCB
No. of rows
2
CS
3.18 mm
Total number of pins
4
Packaging type
Tray
Datasheet (PDF)
Highlights & Details
Molex 438100100 N/A
- Content: 1 pc(s)
- No. of rows: 2
- Total number of pins: 4
Our service for you
Technical specifications
- Packaging type
Tray
- Product type
Pin housing PCB
- No. of rows
2
- Features
+ snap-in nibs
- CS
3.18 mm
- Pins per row
2
- Total number of pins
4
- Content
1 pc(s)
- Connection
Print
- Connection angle
90°
- Manufacturer part #
438100100
- Connector contact surface
Gold (Au)
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Type
438100100
- Engineering Series Name
N/A
- Engineering Series No
43810
Documents & Downloads
Datasheet
Datasheet 2760011 Molex Pin housing PCB Total number of pins 4 Contact spacing: 3.18 mm 438100100 1 pc(s) Tray
User & Safety Instructions
User & Safety Instructions 2760011 Molex Pin housing PCB Total number of pins 4 Contact spacing: 3.18 mm 438100100 1 pc(s) Tray
Description
Mini-Fit BMI Header, Dual Row, Right-Angle, for 3.18mm PCB, 4 Circuits, Gold (Au) Plating, 260C Wave Solderable, with Retention Clip
