Image similar
Molex Pin strip (standard) Total number of pins 16 901303316 1 pc(s) Tray
EAN:
Part number:
Item no:
Product type
Pin strip (standard)
No. of rows
2
Total number of pins
16
Packaging type
Tray
Content
1 pc(s)
Datasheet (PDF)
Highlights & Details
Molex 901303316 .100 HDR HOUSING
- Content: 1 pc(s)
- No. of rows: 2
- Total number of pins: 16
Our service for you
Technical specifications
- Packaging type
Tray
- Product type
Pin strip (standard)
- No. of rows
2
- Total number of pins
16
- Content
1 pc(s)
- Connection
Print
- Connector coating thickness
0.76 µm
- Manufacturer part #
901303316
- Contact material
Gold
- Connector contact surface
Partially gold plated
- RoHS-compliant
Yes
- Connector orientation
Parallel (to the PCB)
- Type
901303316
- Engineering Series Name
.100 HDR HOUSING
- Engineering Series No
90130
Documents & Downloads
Datasheet
Datasheet 2760196 Molex Pin strip (standard) Total number of pins 16 901303316 1 pc(s) Tray
User & Safety Instructions
User & Safety Instructions 2760196 Molex Pin strip (standard) Total number of pins 16 901303316 1 pc(s) Tray
Description
C-Grid III Header, Dual Row, Right-Angle, Shrouded, Fully Loaded, 16 Circuits, Black 0.76µm Gold (Au) Selective Plating
