1/5
Technical specifications
- Product type
Motherboard
- Chipset
Intel® Z690
Intel® 1700
- Form factor
ATX
- Processor/type
Gen 12 Intel Core/Pentium/Celeron
- RAM type
DDR4 SDRAM
- Interfaces
Gigabit LAN (1/2.5 Gbps)
- No. of DDR4 slots
4 x
- No. of LAN ports
1 x
- No. of Gigabit LANs
1 x
- No. of PCIe 3.0 x16
3 x
- No. of PCIe x16
3 x
- No. of PCIe x1
1 x
- No. of USB 2.0 ports
4 x
- No. of USB type A 3.0 ports
2 x
- No. of USB 3.0 ports
2 x
- No. of SATA III ports
6 x
- Onboard audio
7.1
- Depth
244 mm
- Height
65 mm
- Width
305 mm
- Design height
65 mm
- No. of 10 Gb LAN ports
1 x
- No. of DisplayPort
1 x
- No. of HDMI ports
1 x
- Weight
1 kg
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2842074 MPG Z690 EDGE WIFI Motherboard PC base Intel® 1700 Form factor (details) ATX Motherboard chipset Intel® Z690
Description
Features
- Processor manufacturer: IntelLGA 1700 processor socketCompatible processors: Intel® Core™ i3Intel® Core™ i5Intel® Core™ i7Intel® Core™ i9. Supported memory: DDR4 SDRAMRAM maximum: 128 GBRAM type DIMM. Supported drive interfaces: M.2SATA. Parallel processing technology: Crossfire. Ethernet interface type 2.5 Gigabit EthernetLAN-Controller Intel I225-VTop-WLAN standard Wi-Fi 6E (802.11ax)
