Multicolour Hager SPB413
Number of pins
4
Factory colour
Multicolour
Dim
(W x H x D) 85 x 80 x 110 mm
Width
85 mm
Height
80 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Factory colour
Multicolour
- Number of pins
4
- Dim
(W x H x D) 85 x 80 x 110 mm
- Width
85 mm
- Height
80 mm
- Depth
110 mm
- Weight
0.39
DIN rail (top hat rail) 35 mm
FALSE
4 modular spacing
275 V
400 V
Optic
35 mm²
25 mm²
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2819905 Multicolour Hager SPB413
Description
Surge suppressor T2 4P 40kA TT/TNS Fault display. Surge suppressor type 2 in 3+1 circuit for protection of three-phase TT and TN-S systems. Consisting of a four-way base element, three protective plugs with temperature-monitored high performance varistor and a plug as total current spark gap with dynamic separator. Visual fault warning on plugs in case of overload. Connections for the active conductor from below for earthing/PE and telecommunications contact from above. Biconnect-terminals for connection of round conductors and wiring bridges. Labelling possibility on the base element.
