Nowax 1582036421 TDN 1200 Submersible pump PG connector 4800 l/h 48 m
EAN:
Part number:
Item no:
Highlights & Details
Stainless steel 5" Submersible pressure pump TDN 1200
- Sealed ball bearing
- Integrated thermal protection switch
- Rainwater Harvesting
Technical specifications
- Cable type: H07RN-F
- Current consumption: 4.3 A
- Capacitor: 16.0 µF
- Grain size (max.): 2.5 mm.
- Product type
Submersible pump
- Features
PG connector
- Max. delivery head
48 m
- Max. feed rate
4800 l/h
- Max. discharge pressure
4.8 bar
- Operating voltage
230 V
- Power (P2)
1000 W
- Pressure connection
39.0 mm (1 1/4") IT
- Type
Submersion Pressure Pump TDN 1200
- Immersion depth
17 m
- Max. cable length
20 m
- Operating time (OT)
Non-stop
- Float switch
Yes
- Overload protection
Yes
- Length
590 mm
- Width
200 mm
- Height
180 mm
- Dim
(L x W x H) 590 x 200 x 180 mm
- Weight
15.2 kg
IP68
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1606904 Nowax 1582036421 TDN 1200 Submersible pump PG connector 4800 l/h 48 m
User & Safety Instructions 1606904 Nowax 1582036421 TDN 1200 Submersible pump PG connector 4800 l/h 48 m
Information
Information 1606904 Nowax 1582036421 TDN 1200 Submersible pump PG connector 4800 l/h 48 m
Description
Main features:
Pump housing, break-in filter and shaft made of stainless steel. Running/tail wheels made of glass-fiber reinforced plastic. Double mechanical seal in Olvorlage. Stationary and mobile operation possible, also suitable for continuous operation. With the automatic operation with float switch.
Applications:
Water supply from tanks
Cisterns and wells
Irrigation, pressure increase
This text is machine translated.
Pump housing, break-in filter and shaft made of stainless steel. Running/tail wheels made of glass-fiber reinforced plastic. Double mechanical seal in Olvorlage. Stationary and mobile operation possible, also suitable for continuous operation. With the automatic operation with float switch.
Applications:
Water supply from tanks
Cisterns and wells
Irrigation, pressure increase
This text is machine translated.
Scope of delivery
- Submersible pump
- 20 m power cable with earthing contact plug
- The float switch.
