OBO Bettermann 5015832 1802 6 CU Electrical bonding 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Design = structure fix
- Design = only terminal
- Insulator = Yes
- Number of connections round conductors, total=6
- Number of connections round conductor 8 mm = 0
- Number of connections round conductor 10 mm = 0
- Number of connections round conductor 8-10mm = 0
- Number of connections ribbon cables up to 30 mm = 0
- Number of connections ribbon cables up to 40 mm = 0
- Number of ports line up to 6 mm² rigid = 0
- Number of ports line up to 16mm² rigid = 0
- Number of connections cable up to 25 mm² rigid = 0
- Number of connections cable up to 95 mm² rigid = 0
- The contact rail material = copper
- Surface of the contact rail = untreated
- Material of the clip = Steel
- Surface of the clip = galvanically/Electrolytically galvanised
- Product type
Electrical bonding
- Manufacturer part #
5015832
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1964104 OBO Bettermann 5015832 1802 6 CU Electrical bonding 1 pc(s)
Description
Main Equipotential bonding rail for the potential compensation according to DIN VDE 0100-410/540 as well as lightning protection potential compensation according to DIN VDE 0185-305 (IEC 62305), with Lock screw M10 for connecting different conductor by means of appropriate cable lugs or holes
