OBO Bettermann 5093252 DS-BNC M/W Data network surge protection 5 kA 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- The highest continuous voltage AC = 130 V
- The highest continuous voltage DC = 185 V
- Lightning impulse current (10/350 μs) = 2.5 kA
- Nominal surge current (8/20) 5 kA
- Nominal load current = 10 A
- Protection level = 800 V
- Protection level wire/wire = 800 V
- Protection level wire/Earth = 800 V
- 2.0 MHz frequency = 0.
- Cut-off frequency = 2200MHz
- Mounting type=connector/cable adapter
- Connection 1 = BNC
- 50 Ohm
- Surge arrester monitoring = No
- With remote signalling contact = No
- Explosion tested design = No
- Product type
Data network surge protection
- Leakage current
5 kA
- Manufacturer part #
5093252
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1962592 OBO Bettermann 5093252 DS-BNC M/W Data network surge protection 5 kA 1 pc(s)
Description
With 1 sockets and 1 plug connection, transmission frequency 0 to 2.5 GHz
