OBO Bettermann 5095600 C20-0-255 Surge protection device 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Number of poles: 1
- Highest continuous voltage AC 255 V
- Nominal voltage AC 230 V
- Protection level 1.3 kV
- Suppression load 0.1 kA
- Mounting type: On base element
- Installation size 1 TE
- Signalling at device: Optical
- Integrated fuse: No.
- Protection class (IP) IP20
- Product type
Surge protection device
- Surge protection for
Switchboards
IP20
- Manufacturer part #
5095600
- Content
1 pc(s)
- Number of pins
1
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3162039 OBO Bettermann 5095600 C20-0-255 Surge protection device 1 pc(s)
Description
Upper section, N-PE surge suppressor type 2
For overvoltage protection-potential equalization according to VDE 0100-443 (IEC 60364-4-44)
Discharge capacity up to 40 kA (8/20) per pin through high-performance varistors
Modular pluggable arrester with separating device and optical status display
Locking function with vibration protection and voltage coding
Plastic according to UL 94 V-0
Potential equalization in main and sub-distributions.
This text is machine translated.
For overvoltage protection-potential equalization according to VDE 0100-443 (IEC 60364-4-44)
Discharge capacity up to 40 kA (8/20) per pin through high-performance varistors
Modular pluggable arrester with separating device and optical status display
Locking function with vibration protection and voltage coding
Plastic according to UL 94 V-0
Potential equalization in main and sub-distributions.
This text is machine translated.
