OBO Bettermann 5098427 MDP-3 D-24-T Surge protection device 5 kA 1 pc(s)
EAN:
Part number:
Item no:
Technical specifications
- Nominal voltage DC = 24 V
- The highest continuous voltage AC = 20 V
- The highest continuous voltage DC = 28 V
- Nominal surge current (8/20) 5 kA
- Nominal load current = 0.58 A
- Protection level wire/wire = 65 V
- Protection level wire/Earth = 750 V
- Signaling on the device = can be read
- Mounting type = TH 35 standard mounting rail
- Connection 1 = terminal
- With remote signalling contact = No
- Explosion tested design = No
- Product type
Surge protection device
- Leakage current
5 kA
- Nominal voltage
24 V
- Manufacturer part #
5098427
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1964587 OBO Bettermann 5098427 MDP-3 D-24-T Surge protection device 5 kA 1 pc(s)
Description
The internal schaltungsstrukur permits the use in a wide range of measurement and control circuits from voltage-controlled signal applications up to 4-20 mA sensors. The capacitance and inductance arms protective circuit allows the use in the DC area to - 100 M Hz-Signalen. With the help of the test device life control can be integrated protective elements in running test, without which the actual measuring circuit affected or interrupted. The removal of the protection device or the disconnection of the signal circuit is not necessary. Optionally, it is possible single or multiple flash barriers to be connected to each other via a common ground bridge
