OBO Bettermann 6108051 Plug White
EAN:
Part number:
Item no:
Technical specifications
- Color of the insulation: white
- Product type
Plug
- Nominal voltage
250 V
- Nominal current
16 A
- Factory colour
White
- Connection
Spring-loaded terminal
- Cable Ø (max.)
10.33 mm
- Cable Ø up to
7.8 mm
- Cable Ø range
7.8 - 10.33 mm
- Number of pins
3
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1963440 OBO Bettermann 6108051 Plug White
Description
3-pole male connector with spring-cage connection for rigid lines of 1.5 - 2.5 mm², single or ultrasonic welding, fine lines 1.5 mm² with wire-end sleeves, UNASSEMBLED with strain-relief, on-site configurable, coding black, 250 V, 16 A. 2 connections per pin, for cables with H05VV, NYM (Ø 7.8 - 10,33 mm), lockable, in accordance with strain relief according to VDE0628 is a lock must be provided.
