OBO Bettermann 6108056 Socket Black
EAN:
Part number:
Item no:
Technical specifications
- Number of pins: 3
- Connection type: screw terminals.
- Design: Jack
- Cable diameter: 10.5. 10.5 mm
- Connection cross-section (fine): 2.5.2.5 mm²
- Connection cross-section (solid): 2.5. 2.5 mm²
- Number of connections each pole: 1
- Mechanical coding: yes
- Color of the coding/contact insert: black
- With strain relief: yes
- Material of the housing: polyamide (PA)
- Product type
Socket
- Nominal voltage
250 V
- Nominal current
16 A
- Factory colour
Black
- Connection
Screw connection
- Cable Ø (max.)
10.5 mm
- Cable Ø up to
6.5 mm
- Cable Ø range
6.5 - 10.5 mm
- Number of pins
3
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1964397 OBO Bettermann 6108056 Socket Black
Description
Socket 3-pin screw terminal connection, low profile (no slot loss in combination with distribution blocks), for cross-section 0.75 - 2.5 mm², and stranded conductors without wire end sleeve can be connected, for wire diameters from 6.5 to 10.5 mm (H05VV, NYM), UNASSEMBLED with strain-relief, on-site configurable, 250 V, 16 A
