OBO Bettermann 6182713 Small angle bracket (W x H) 230.00 mm x 100.00 mm 1 pc(s) White
EAN:
Part number:
Item no:
Technical specifications
- Height: 100 mm
- Width 230 mm
- Design: Lower part and upper part
- Angle 90 °
- Material: Plastic
- Material quality: Polyvinyl chloride (PVC)
- Halogen-free: No.
- Antibacterial treatment: No.
- Suitable for functional preservation: No.
- Colour: white
- RAL number: 9010
- With protective film: No.
- Mounting type: Floor holes
- Protection class (IP) IP30
- Impact strength: IK04
- Operating temperature -5..60°C
- Product type
Small angle bracket
- Type
Lower and upper part
- Content
1 pc(s)
- Factory colour
White
- Dim
(W x H) 230.00 mm x 100.00 mm
- Width
230.00 mm
- Height
100.00 mm
IP30
- Material (details)
Plastic
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3162452 OBO Bettermann 6182713 Small angle bracket (W x H) 230.00 mm x 100.00 mm 1 pc(s) White
Description
Flat angle for changing the direction of the WDK channels.
