Panasonic Electrolytic capacitor SMD 220 µF 10 V 20 % 1 pc(s) Tape
Packaging type
Tape
Product type
Electrolytic capacitor
Type
SMD
Capacity (elec.)
220 µF
Nominal voltage
10 V
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
Panasonic SMD electrolytic capacitor 220UF 10V 6.7.7mm
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series FK
- Qualification: AEC-Q200
- Design_1: D
- Technology: Aluminium electrolytic capacitor
- Mounting type_1: SMD
- Delivery form_1: Taped
- Properties_1: • Low impedance
- • Endurance: 105°C 2000h
- • miniaturized
- • AEC-Q200 compliant
- Capacity 220 µF
- Capacity_1: 220
- Unit of capacity: µF
- Capacity Tolerance 20%
- Loss factor tan δ: 0.19
- Ripple current 280 mA
- Equivalent Series Resistance (ESR): 0.34 ohms
- Nominal voltage DC 10 V
- Lifetime_1: 2,000 h
- Packaging type
Tape
- Product type
Electrolytic capacitor
- Type
SMD
- Capacity (elec.)
220 µF
- Nominal voltage
10 V
- Tolerance ±
20 %
- Height
7.7 mm
- Content
1 pc(s)
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
105 °C
- Type
EEEFK1A221XP
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-55 °C
Documents & Downloads
Datasheet
Datasheet 3465892 Panasonic Electrolytic capacitor SMD 220 µF 10 V 20 % 1 pc(s) Tape
User & Safety Instructions
User & Safety Instructions 3465892 Panasonic Electrolytic capacitor SMD 220 µF 10 V 20 % 1 pc(s) Tape
Description
Alu Elko SMD series FK_P/R
