Panasonic MKP thin film capacitor Radial lead 0.68 µF 450 V 5 % (L x W x H) 17.5 x 7.0 x 12.5 mm 1 pc(s)
Product type
MKP thin film capacitor
Type
Radial lead
Capacity (elec.)
0.68 µF
Nominal voltage
450 V
Dim
(L x W x H) 17.5 x 7.0 x 12.5 mm
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
Panasonic MKP 0.68UF 450V 5% RM15
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series ECWFE
- Design_1: Radial
- Applications: Active filter circuits as well as high-frequency and high-current circuits
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 2-pin
- Properties_1: Plastic foil capacitors
- Dielectric made of polypropylene (PPT) film, metalized
- Flame-retardant epoxy resin coating
- Small dimensions
- Excellent frequency characteristics
- Low losses
- Pitch_1:15.0 mm
- Capacity 0.68 µF
- Capacity_1: 0.68
- Unit of capacity: µF
- Capacity Tolerance 5%
- Dielectric: Metallized PP film
- Nominal voltage DC 450 V
- Insulation value in sec.: 10,000 sec.
- Product type
MKP thin film capacitor
- Type
Radial lead
- Dim
(L x W x H) 17.5 x 7.0 x 12.5 mm
- Capacity (elec.)
0.68 µF
- Nominal voltage
450 V
- Tolerance ±
5 %
- Height
12.5 mm
- Content
1 pc(s)
- Width
7.0 mm
- Length
17.5 mm
- RoHS-compliant
Yes
- Type
ECWFE2W684J
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-40 °C
Documents & Downloads
Datasheet
Datasheet 3463505 Panasonic MKP thin film capacitor Radial lead 0.68 µF 450 V 5 % (L x W x H) 17.5 x 7.0 x 12.5 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463505 Panasonic MKP thin film capacitor Radial lead 0.68 µF 450 V 5 % (L x W x H) 17.5 x 7.0 x 12.5 mm 1 pc(s)
Description
Panasonic MKP-capacitors series ECWFE
