PC Electric CEE power distributor Sölden 9029074 400 V
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- 1 x hole M40 top, 1 x blind screw connection M40 bottom
- 1 x CEE-socket 63A 5P 400V secured d. Feed-in fuse
- 1 x CEE-socket 32A 5P 400V secured ü. 1 x LS 32A 3P C
- 2 x CEE-socket 16A 5P 400V secured ü. 1 x LS 16A 3P C
- 3 x SK socket 16A 250V IP54 secured ü. 3 x LS 16A 1P C
- 1 x FI 63A/4/0.03A (TYPE A 63AT) via all outputs
- Circuit breaker switch and FI manufacturer Eaton EVE / VDE
- Distributor on HVAC terminal (max. 5 x 25 qmm/5 x 16 qmmYF!) wired
- Number of circuit breakers: 5
- Feed/connection option: 2 lines (loop/loop-through)
- Product type
CEE power distributor
- Type A
CEE socket (5-pin, 16 A)
CEE socket (5-pin, 32 A)
CEE socket (5-pin, 65 A)
- Type B
PG socket
- No. of PG sockets
3
- Nominal input voltage
400 V
IP54
IK08
- Min. temperature
-25 °C
- Max. temperature
40 °C
- Factory colour
Grey
- Dim
(W x H x D) 297 x 520 x 165 mm
- Width
297 mm
- Height
520 mm
- Content
1 pc(s)
- Number of pins
5
- Depth
165 mm
Documents & Downloads
Datasheet
Datasheet 2389953 PC Electric CEE power distributor Sölden 9029074 400 V
Description
Wall distributor plastic series SÖLDEN BV 63/5 32/5 2x16/5 3xSSD M40Ooa IP54, 14TE.
This text is machine translated.
This text is machine translated.
Features
- 4-way wall mounting outside as well as inside
- Protection class II (standard)
- Brass insert for lid mounting
- Captive cover screws
- Hinges between the bottom of the housing and the cover
- Excellent impact resistance
- High temperature and shape resistance
- Very good electrical insulating properties
- Weather-, UV-resistance tested according to ISO 4892-2
- Good ozone resistance
- Installation type: Open air and interior
- Good resistance to aging and corrosion
- Resistant to various oils, weak acids, etc.
- Housing made of PC/ABS
- Glow wire resistant 750°C according to EN 60695-2-11
- HB according to UL94
- Rated insulation voltage 690 V.
- High mechanical strength, up to IK08 according to EN 50102 / EN 62262
- Transport and storage temperatures: -25 °C to +55 °C / short-term 24 h to +70 °C.
- Special operating conditions must be agreed between PCE and the user
- External cover screws V2A quality.
