PCB connector USB socket, Type C, USB 3.1, 10 Gb/s , SMD solder connection, Roll PCB socket, right angle USB3.1C S1V 1.7
EAN:
Part number:
Item no:
Product type
PCB connector
Connector type
PCB socket, right angle
Number of pins
24
USB type
C®
Connector standard
USB-C® socket
Datasheet (PDF)
Technical specifications
- Type
USB3.1C S1V 1.7N4 RL
- Type
Fixed connector
- Product type
PCB connector
- Connector type
PCB socket, right angle
- Number of pins
24
- USB type
C®
- Connector standard
USB-C® socket
- Connection
SMD
- Connection
90° (vertically upward)
- Manufacturer part #
3158920000
- Factory colour
Black
- Content
2000 pc(s)
- Contact material
Gold
- Material
LCP
- Nominal voltage (details)
20 V
- Nominal current (details)
5 A
- Max. temperature
85 °C
- Min. temperature
-40 °C
Flexible PCB-connector
Black
20 V
24
Other
-40-85 °C
Solder
9011
SMD-connection
Gold
0.5 mm
1
Other
Fixed connector
Liquid crystal polymer
90° (upwards vertical)
Flange
5 A
V0
Documents & Downloads
Datasheet
Datasheet 3749663 PCB connector USB socket, Type C, USB 3.1, 10 Gb/s , SMD solder connection, Roll PCB socket, right angle USB3.1C S1V 1.7
User & Safety Instructions
User & Safety Instructions 3749663 PCB connector USB socket, Type C, USB 3.1, 10 Gb/s , SMD solder connection, Roll PCB socket, right angle USB3.1C S1V 1.7
Description
PCB connector for USB data cables
