PCE Instruments PCE-LES 500-ICA LED strobe No. of LEDs (details):28 x

Our extremely bright, portable LED stroboscope is unsurpassed in light intensity, operation and technology. This very robust and precise hand-held stroboscope is used for measurements in demanding industrial environments and is specially designed for maintenance, commissioning and inspection. The operation is very simple: Fast moving parts are optically "frozen" and thus made visible to the human eye. In this way defective components or sub-optimal settings can be determined and corrected during operation.

With its large measurement range from 50 to 50,000 FPM, it is versatile and offers precise measurements for a variety of applications. Through its compact size and its low weight it is extremely handy and can be taken everywhere. Equipped with 28 energy-saving and long-life LEDs as a light source, the portable LED stroboscope guarantees reliable performance and a long service life. With a resolution of 0.1 FPM and an accuracy of 0.01%, it provides extremely precise measurement results, which meet even the highest demands. It is used especially for measuring steel and aluminum coils, flat railways or other rotating objects.

In addition, the portable LED stroboscope has an impressive light intensity of 2439 Lux at 50,000 FPM and a distance of 20 cm. The adjustable phase shift from 0 to 360 degrees enables precise synchronization with other devices or processes and makes it an extremely versatile tool. The portable LED stroboscope has a trigger input for external control and other features such as an ergonomic handle for convenient handling as well as a robust metal housing that ensures safe use even in harsh environments. The removable battery provides a comfortable power supply on the way, an additional spare battery extends the operating time.

This text is machine translated.
