Name: PCE Instruments PCE-THB 38 Pressure gauge Temperature, Condensation point, Humidity, Atmospheric pressure
Brand: PCE Instruments
SKU: 2452684

Handheld humidity and temperature meter with digital display and probe, showing 94.5 and 16.9 on the screen.

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Barometer PCE-THB 38

Measures temperature, humidity, barometric pressure
Calculates the dew point
Pressure unit selectable: HPa, (mbar), mmHg and inHg
Low battery indicator
Min- / Max-Hold function
Internal sensor, well protected
good value for money
lightweight and easy to use

Technical specifications

Technical specification Measurement ranges: Temperature Relative humidity Barometric pressure Dew point (is calculated) 0 ... + 50°C. 10 ... 95%RH 10 ... 1100 hPa (mbar) -25 ... 49 °C Resolution Temperature Relative humidity Barometric pressure Dew point - 0.1°C - 0.1%RH - 0.1 hPa to 1000 hPa, otherwise 1 hPa - 0.01°C. Accuracy Temperature Relative humidity Barometric pressure ± 0.8 °C ± (3% v.MW + 3% r.F.) ± 1.5 hPa to 1000 hPa, otherwise ±2 hPa Ambient temperature 0 ... +50 °C Power supply 4 x 1.5V batteries (AAA) Dimensions 210 x 40 x 40 mm Weight (incl. battery) 160 g

Product type: Pressure gauge

Unit of measurement: Temperature
Condensation point
Humidity
Atmospheric pressure

: Manufacturer's standards (no certificate)

Dim: (L x W x H) 210 x 40 x 40 mm

Weight: 160 g

Width: 40 mm

Height: 40 mm

Length: 210 mm

Documents & Downloads

Datasheet

Datasheet 2452684 PCE Instruments PCE-THB 38 Pressure gauge Temperature, Condensation point, Humidity, Atmospheric pressure

User & Safety Instructions

User & Safety Instructions 2452684 PCE Instruments PCE-THB 38 Pressure gauge Temperature, Condensation point, Humidity, Atmospheric pressure

Description

Thermometer, humidity meter and barometer in one measuring device (with dew point calculation) the barometer PCE-THB 38 is suitable for measuring and digital display of the relative air humidity, the ambient temperature and the barometric pressure. The temperature is measured with an RTD sensor and the relative humidity with a capacitive sensor with high repeatability. In addition, the barometer also calculates the dew point. The barometer also shows the atmospheric pressure in a range of 10 - 1100 hPa. Thus, with this device you have a complete air-conditioning measuring device.
