Name: PCE Instruments PCE-THB 40 PCE-THB 40 Multi-channel data logger Unit of measurement Humidity, Temperature 0 up to 50 °C
Brand: PCE Instruments
SKU: 2452685

PCE-THB 40 humidity, barometric pressure and temperature data logger with SD card, shown with a memory card and spreadsheet data display.

A digital measuring device with a display shows '3749' for air pressure, '20.8' for temperature and '39.84' for humidity. Beside it lies an SD card.

1/2

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

PCE Instruments PCE-THB 40 PCE-THB 40 Multi-channel data logger Unit of measurement Humidity, Temperature 0 up to 50 °C 0 up to 90 RH

Measures temperature, humidity, barometric pressure
Flexible internal real-time data storage via SD memory card (1 ... 16GB)
The saved data is stored directly as an Excel file on the SD card
Pressure units can be selected

Technical specifications

Measurement ranges: Temperature 0 ... + 50°C. Relative humidity 10 ... 90 % r.F. Barometric pressure 10 ... 1100 hPa (mbar) Resolution Temperature 0.1°C. Relative humidity 0.1% r.h. Barometric pressure 0.1 hPa to 1000 hPa (otherwise 1 hPa) Accuracy Temperature ±0.8 °C. Relative humidity ±4 % r.h. Barometric pressure ±2 hPa to 1000 hPa, otherwise ±3 hPa Measurement rate 5, 10, 30, 60, 120, 300 or 600 seconds or automatically (if the value is changed by ±1 °C, ±1 % r.h. or ±1 hPa, the data record is automatically written to memory) Data memory flexible via SD card memory 1 ... 16 GB (2 GB SD card included in delivery) Ambient temperature 0 ... +50 °C< 90 % RH Power supply 6 x 1.5 V battery (AAA) / 9 V mains adapter (optional) Dimensions 132 x 80 x 32 mm Weight (incl. battery) 285 g

Product type: Multi-channel data logger

Unit of measurement: Humidity
Temperature

Temperature reading range (min.): 0 °C

Temperature reading range (max.): 50 °C

: Manufacturer's standards (no certificate)

Dim: (L x W x H) 132 x 80 x 32 mm

Weight: 285 g

Humidity reading range (max.): 90 RH

Humidity reading range (min.): 0 RH

Temperature reading range: 0 up to 50 °C

Width: 80 mm

Height: 32 mm

Length: 132 mm

Power supply: AAA battery (6x)

Type: PCE-THB 40

Documents & Downloads

Datasheet

Datasheet 2452685 PCE Instruments PCE-THB 40 PCE-THB 40 Multi-channel data logger Unit of measurement Humidity, Temperature 0 up to 50 °C

User & Safety Instructions

User & Safety Instructions 2452685 PCE Instruments PCE-THB 40 PCE-THB 40 Multi-channel data logger Unit of measurement Humidity, Temperature 0 up to 50 °C

Description

Thermometer, humidity meter and barometer with SD memory card / large LCD display / different units can be selected / Battery or mains operation (optional) possible The barometer records the air temperature as well as the relative humidity and barometric pressure and stores them internally on an SD card. The compact device with a large memory (up to max. 16 GB SDHC card) is used primarily for long-term registration in the food sector (cold stores in department stores, cold transports, warehouses) as well as for measurement and recording in industry (heating and cooling processes, machine temperatures, product storage, ...).the current measured value is displayed directly on the LCD display and also stored in the data memory, so that you can either read the value directly or transfer the values stored on the SD card to a PC or laptop at will and evaluate these graphically as a history curve. The values recorded in the barometer function can of course also be transferred back to the PC and evaluated (.xls file on the SD card). In addition, you can check the number columns for outliers, and in the case of the food industry, you can quickly determine whether and, if necessary, how long the cooling chain has been interrupted. The internal real-time clock with date allows the user to precisely assign the events. The measurement rate is freely adjustable. The electronics of the barometer are protected against shocks and robust handling in industry.

This text is machine translated.
