Pepperl+Fuchs 240775-0046 Sensor/actuator connector M12 Plug, straight, Socket, straight 5.00 m No. of pins (RJ): 8 1 pc
EAN:
Part number:
Item no:
Product type
Sensor/actuator connector
Connector type
Plug, straight
Socket, straight
Connector standard
Sensor connector
Connection side A
M12 socket, straight
Connection side B
M12 plug, straight
Datasheet (PDF)
Technical specifications
- Contact elements: Spring-mounted contact sockets
- Pin diameter 1 mm
- Grip body: TPU, black
- Cable material: Pure
- Cable wires 8 x 0.25 mm²
- Cable sheath diameter: Ø 6 mm
- Cable bending radius:> 10 x cable diameter, moving, 8 x cable diameter, fixed v.
- Packaging type
Piece
- Type
V19-G-BK5M-PUR-U-V19-G
- Product type
Sensor/actuator connector
- Connector type
Plug, straight
Socket, straight
- Connector standard
Sensor connector
- Connection side A
M12 socket, straight
- Connection side B
M12 plug, straight
- No. of pins
8
- Cable length
5.00 m
- Jacket material
PUR
- Nominal voltage
30 V DC/AC
- Nominal current
2 A
- Nominal current - rounded value
2 A
- Cross-section (sensor/actuator wiring)
0.25 mm²
- Connection
Socket
Plug
- Factory colour
Black
- Thread type connection side
M12
- Thread type (wiring and installation)
M12
- Cable colour
Black
- Coding
A
- Contact material
CuSn
- Contact surface
Au
- Features
A-coded
- Min. temperature
-40 °C
- Max. temperature
+90 °C
- Manufacturer part #
240775-0046
- Content
1 pc(s)
- Cable Ø
6 mm
- UKCA
yes
