Name: Pepperl+Fuchs Reflective light barrier GL5-J/43a/155 806133 Light-ON 1 pc(s)
Brand: Pepperl+Fuchs
SKU: 2628930

Optoelectronic U-shaped sensor in a black housing with six pins, used for detecting interruptions or objects.

Image similar

Product type

Reflective light barrier

Functions

Light-ON

Max. operating voltage

24 V DC

Connector

Plug (4-pin)

Type

GL5-J/43a/155

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Reflective light barrier

Type: GL5-J/43a/155

Functions: Light-ON

Min. operating voltage: 5 V DC

Max. operating voltage: 24 V DC

Operating voltage: 5 - 24 V DC

Outputs: 2x PNP Antivalent

Connector: Plug (4-pin)

Enclosure material: PBT

Transmitter type: IRED

Wavelength: 940 nm

Min. temperature: -25 °C

Max. temperature: 55 °C

Content: 1 pc(s)

Wireless charging: No

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2628930 Pepperl+Fuchs Reflective light barrier GL5-J/43a/155 806133 Light-ON 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2628930 Pepperl+Fuchs Reflective light barrier GL5-J/43a/155 806133 Light-ON 1 pc(s)

Description

Fork width: 5 mm, obstacle size: 0.8 x 1.8 mm, light transmitter: IRED, type of light: infrared, direct light, 940 nm, Signal output: 2 PNP antivalent, overvoltage-resistant, switching mode: Light/dark switching, connection: Spade connector, 4-pin, Operating voltage 5 ... 24 V DC , class 2, ambient temperature: -25 ... 55 °C (-13 ... 131 °F)

This text is machine translated.

Features

General dataLight transmitter: IREDType of light: infrared, DC, 940 nmObstacle size 0.8 x 1.8 mmFork width: 5 mmFunctional safety characteristicsMTTFd: 3760 a.Service life (TM): 20 a.Diagnostic coverage level (DC): 0%Displays/controlsFunction display: Red LED lights up when the transmission beam is receivedElectrical DataOperating voltage 5 ... 24 V DC, class 2OutputSwitching type: Light/dark switchingSignal output: 2 PNP antivalent , over-voltage resistantCompliance with standards and directivesCompliance EMC DIRECTIVE 2004/108/EC: EN 60947-5-2:2007+A1:2012Ambient conditionsPollution level: 2Mechanical data:Protection class: IP50Connection: Flat plug, 4-pinMaterials PBT casing

Hints

For more information on this 806133, please refer to its datasheet under 'downloadable documents'
