Pepperl+Fuchs Reflective light barrier GL5-R/43a/115-5M 311659 Switch (light-ON/dark-ON) 1 pc(s)
EAN:
Part number:
Item no:
Product type
Reflective light barrier
Functions
Switch (light-ON/dark-ON)
Max. operating voltage
24 V DC
Connector
Cable
Type
GL5-R/43a/115-5M
Datasheet (PDF)
Technical specifications
- Product type
Reflective light barrier
- Type
GL5-R/43a/115-5M
- Functions
Switch (light-ON/dark-ON)
- Min. operating voltage
5 V DC
- Max. operating voltage
24 V DC
- Operating voltage
5 - 24 V DC
- Contact type
Antivalent
- Outputs
2x PNP Antivalent
- Connector
Cable
- Cable length
5 m
- Enclosure material
PBT
- Transmitter type
IRED
- Wavelength
940 nm
- Min. temperature
-25 °C
- Max. temperature
55 °C
- Width
13.2 mm
- Height
13.4 mm
- Depth
8.5 mm
- Dim
(W x H x D) 13.2 x 13.4 x 8.5 mm
- Content
1 pc(s)
- Wireless charging
No
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2629016 Pepperl+Fuchs Reflective light barrier GL5-R/43a/115-5M 311659 Switch (light-ON/dark-ON) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2629016 Pepperl+Fuchs Reflective light barrier GL5-R/43a/115-5M 311659 Switch (light-ON/dark-ON) 1 pc(s)
Description
Hints
For more information on this 311659, please refer to its datasheet under 'downloadable documents'
