Name: Pepperl+Fuchs Retroreflective light barrier OBG5000-R101-EP-IO-0,3M-V3 267075-100070 Push-pull (inverted) Contrast detec
Brand: Pepperl+Fuchs
SKU: 2628755

A rectangular sensor with a black casing and a red front window. Two circular connectors are visible.

Image similar

Packaging type

Piece

Product type

Retroreflective light barrier

Functions

Contrast detection

Max. operating voltage

30 V DC

Connector

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Packaging type: Piece

Product type: Retroreflective light barrier

Type: OBG5000-R101-EP-IO-0,3M-V3

Model: Push-pull (inverted)

Functions: Contrast detection

Min. operating voltage: 10 V DC

Max. operating voltage: 30 V DC

Operating voltage: 10 - 30 V DC

Response time: 1 ms

Outputs: NPN NO
PNP NC

Switching frequency: 500 Hz

Connector: M8

Cable length: 0.3 m

Enclosure material: Polycarbonate (PC)

Transmitter type: LED red

: 6 m

Features: LED indicator

Min. temperature: -20 °C

Max. temperature: 60 °C

Length: 0.3 m

Width: 13.9 mm

Height: 33.8 mm

Depth: 18.3 mm

(Ø): 170 mm

Dim: (Ø x H) 170 mm x 33.8 mm

Content: 1 pc(s)

Wireless charging: No

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2628755 Pepperl+Fuchs Retroreflective light barrier OBG5000-R101-EP-IO-0,3M-V3 267075-100070 Push-pull (inverted) Contrast detec

User & Safety Instructions

User & Safety Instructions 2628755 Pepperl+Fuchs Retroreflective light barrier OBG5000-R101-EP-IO-0,3M-V3 267075-100070 Push-pull (inverted) Contrast detec
